Lecture

Conceptual Design

Oral exams October / November 2023

Also in this year Prof. Schembecker offers exam dates in presence in October / November.

The following dates are currently available:

10.10.2023
10:30 - 11:00 / 11:00 - 11:30 / 11:30 - 12:00

21.11.2023
10:30 - 11:00 / 11:30 - 12:00

If you would like to register for an exam, please send an email to assistance.apt.bcitu-dortmundde with your desired exam date.

Please note, however, that we assign the dates in the order of incoming registrations.

If you have any questions, please also contact assistance.apt.bcitu-dortmundde.

Type	Lecture (2 SWS) + Exercise (1 SWS)
Credits	4
Rhythm	Winter Semester
Bachelor / Master	Master
Audience	CIW, BIW, PSE
Language	English
LSF number (VL)	061130
Moodle Room	Moodle WS 23/24

Course Content

The course will present different process synthesis methods including their strengths and weaknesses. The focus of the course will be on the heuristic-numeric approach for conceptual design. An extended set of heuristic rules will be presented for the design and selection of reactors and separation steps. In addition, rules for the design of complex flowsheets will be presented which includes the design of recycle structures. A technical process is used to train the students in applying the rules.

Aquired Competences

The students are able to structure the conceptual design process applying synthesis and analysis steps. They can decide under which constraints a special process synthesis method should be used. Moreover, they are able to apply systematic methods to design and evaluate process concepts for new production processes.

Further Details

Exam	Oral - 30 min
Preliminaries	-
Literature	The slides of the course and any additional materials such as literature lists and website recommendations will be published in the virtual workrooms in Moodle provided for this purpose. Details will be announced at the beginning of the course.

Only the information found in the LSF and the most recent edition of the Modulhandbuch der Fakultät Bio- und Chemieingenieurwesen is binding. The content on this page may not reflect the most up-to-date information
